ENQuick Guide

1

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

register your appliance on: www.whirlpool.eu/register

1. ON-OFF/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet indicator light

7. Display

8. Multizone indicator lights

3

1

2

854 6 97 10 11 12 13

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Only the rst time you do this: ll the salt reservoir

with water.

3. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently prevent-

ing scale buildup on heater, contributing also to better cleaning eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

A

C

D

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the appli-

ance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub. If all-in-one detergents are used, we

recommend using the TABLET button, because it adjusts the program so

that the best washing and drying results are always achieved.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

Program

Programs description

Drying

phase

Natural

Dry

Available

options

*)

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

1.

Eco 50°- Program is suitable to clean normally soiled tableware,

that for this use, it is the most ecient programme in terms of its

combined energy and water consumption, and that it is used to

assess compliance with the EU Ecodesign legislation.

3:35 8.7 0.51

2.

Intensive 65° - Program recommended for heavily soiled crock-

ery, especially suitable for pans and saucepans.

2:45 17.5 1.60

3.

6

th

Sense® 50-60°- For normally soiled dishes with dried food res-

idues. Senses the level of soiling on the dishes and adjusts the

program accordingly.

1:20 - 3:00 7.0 - 14.0 0.70 - 1.10

4.

Fast Wash&Dry 50°

- Normally soiled crockery. Everyday cycle, that

ensures optimal cleaning and drying performance in shorter time.

1.25 11.5 1.10

5.

Crystals 45° - Program for delicate items, which are more sensitive

to high temperatures, for example glasses and cups.

1:40 12.0 1.20

6.

Rapid 30’ 45° - Program to be used for half load of lightly-soiled

dishes with no dried food residues. Without drying.

-

0:30 9.0 0.50

7.

Silent

50° - Suitable for night-time operation of the appliance.

With the lowest noise.

3:30 16.0 1.15

8.

Sanitizing 65° - Normally or heavily soiled crockery, with addi-

tional antibacterial wash. Can be used to perform maintenance

of the dishwasher.

-

1.50 12.0 1.30

9.

Prewash - Use to refresh crockery planned to be washed later.

No detergent to be used with this program.

- -

0:10 4.5 0.01

9. Multizone button

10. Delay button

11. Extra Dry button with

indicator light

12. Power Clean® button

with indicator light

13. START/Pause button with indicator light / Tablet (Tab)

CONTROL PANEL

FIRST TIME USE

More information in the Daily Reference Guide on website.

PROGRAMS TABLE

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.
