ENDaily Reference Guide

3

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: [email protected]

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

PROGRAMS TABLE

Program

Programs description

Drying

phase

Natural-

Dry

Available

options

*)

Duration

of wash

program

(h: min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled table-

ware, that for this use, it is the most ecient program in terms

of its combined energy and water consumption, and that it is

used to assess compliance with the EU Ecodesign legislation.

3:30 9.5 0.76

Rapid 45° - Program is recommended for limited amount

of lightly-soiled dishes with no dried food residues. Does not

include the drying phase.

-

0:30 - 0:40 10.0 - 12.0 0.55 - 0.65

Crystals 45° - Program for delicate items, which are more

sensitive to high temperatures, for example glasses and cups.

1:40 - 1:50 12.5 - 16.5 0.95 - 1.20

Auto Intensive 65° - Automatic pro-

gram for heavily soiled dishes and pans.

Senses the level of

soiling on the dishes

and adjusts the

program accor-

dingly. When the

sensor is detecting

the soil level an

animation appears

in the display and

the cycle duration is

updated.

2:25 - 3:10 15.5 - 24.5 1.30 - 1.70

Auto Mixed 55° - Automatic program

for normally soiled dishes with dried

food residues.

1:20 - 3:00 7.5 - 19.5 0.75 - 1.20

Auto Fast 50° - Automatic program

for normally and lightly soiled dishes.

The everyday cycle that ensures opti-

mal cleaning and drying performance

in shorter time.

1:00 - 1:50 7.5 - 15.5 0.70 - 1.10

Prewash - Use to refresh crockery planned to be washed

later. No detergent is to be used with this program.

-

0:12 4.5 0.10

Self-Clean 65° - Program to be used to perform mainte-

nance of the dishwasher, to be carried out only when the

dishwasher is EMPTY using specic detergents designed for

dishwasher maintenance.

-

-

1:15 11.0 1.10

DESCALE - Alarm - Limescale accumulation was detected on internal

components of the appliance. Check if the Water Hardness Setting is

at the correct value and salt is present in the salt container (see FIRST TIME

USE), then use a descaling product (WPro brand is recommended) with

Self-Clean program. After a successful descaling the icon will stop being

displayed.

If the actions above are not performed, product performance will deteriorate.

DESCALE warning will start blinking and «dES» alarm will appear on the

display. If still no action is taken, the appliance will only allow a certain

number of cycles to be started (indicated during «dES» alarm display)

and then will be BLOCKED to prevent component damage, with only

the Self-Clean program available. Performing a full descaling will unblock

the product. In the case of extremely high amounts of limescale, descaling

may have to be performed twice to be ecient.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(please refer to the Power Clean® in loading section).

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allows for improved drying. The EXTRA DRY

option results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

1. Select the program and any desired options. Press the DELAY button

(repeatedly) to delay the start of the program. Adjustable from 0:30 to 24

hours. Once the 24 hours setting is reached, press the DELAY another time

to deactivate the DELAY function.

2. Press the START/Pause button and close the door within 4 sec. The timer

will begin counting down.

3. Once this time has elapsed, the indicator light switches o and the program

begins automatically.

The DELAY function cannot be set once a program has been started.

WATER TAP CLOSED - Alarm - Flashes when there is no inlet water or

water tap is closed.

NaturalDry - It is a convection drying system which automatically opens

the door during/after the drying phase to ensure exceptional drying

performance every day. The door opens at a temperature that is safe to

your kitchen furniture, thus door will not be opened when the option of

SANI RINSE is on.

As additional steam protection, specially designed protection foil is added

together with the dishwasher.

To see how to mount protection foil please refer to the INSTALLATION GUIDE.

This feature is active by default, but it is possible to deactivate it in

the “SETTINGS MENU”.

HALF LOAD - If there are not many dishes to be washed, HALF LOAD

is used to save water, electricity or time, depending on the selected program.

Remember to reduce the amount of detergent.

SILENT - Suitable for night-time operation of the appliance. This option

can be used to limit noise emissions during wash phases. It will increase

cycle time depending on base cycle selection.

SANI RINSE - This option can be used to sanitize washed dishes. It will

increase the nal rinse temperature and add an antibacterial wash to

the selected program. Ideal to clean crockery and feeding bottles. The

dishwasher door must be kept shut for the entire duration of the program

in order to guarantee a reduction of germs.

WARNING: the crockery and plates could be extremely hot at the end

of the cycle.

SENSING - When the sensor is detecting the soil level an

animation appears in the display (around 20 min.) and the cycle

duration is updated. SENSING is for the level of soiling on the dishes and is

present for all cycles (excepting Eco) adjusting the program accordingly.

OPTIONS AND FUNCTIONS

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator lights up)

(see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and

beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

TIME ON THE FLOOR - A LED light projected on the oor indicates the

time left to the end of the cycle. The light goes o every time the door

is opened. The light goes o at the end of a cycle.This feature is active

by default, but it is possible to deactivate it in the “SETTINGS MENU”.
