Thank you for your decision for aThomson product.

Take your time and read the following instructions

and information completely. Please keep these

instructions in asafe place for future reference.

This remote control can by default control 90%

models of SAMSUNG brand, there´s no need to set

it up. lf the remote doesn‘t work, please choose

one of the setup methods described in chapter 5.

 

1. Input signal source /Indicator LED

2. POWER TV ON /OFF

3. Switch to signal source PC

4. Switch to signal source TV

5. Switch to signal source HDMI

6. Numeric keys 0–9toenter channel

numbers

7. Previous channel

8. Access to 2- or 3- digit channel numbers

9. TV Mute

10. Channel up/down

11. Teletext ON /OFF /MIX

12. Smart TV Menu

13. Change your TV‘s volume

14. Media Player

15. Show the Electronic Program Guide

(if supported by the TV)

16. Program MENU

17. TOOLS MENU

18. On-Screen Info

19. Use when watching TV to see what‘s on

other channels or to highlight/Select

On-Screen options

20. Return /Back key

21. Turn off the menu of the selected product.

22. Use to select avariety of on screen options

23. Sound Mode

24. PictureMode

25. Multi Sound

26. Favorite Channel

27. PictureSize

28. 3D Mode ON/OFF

29. Suspends play and stops on an image

(DVD, BlueRay…)

30. Fast Forward(DVD, BlueRay ... )

31. Goes backward(DVD, BlueRay ... )

32. Stop the disc (DVD, BlueRay ... )

PIP (PictureinPicture)

33. Play adisc (DVD, BlueRay ... )

PIP Position

34. Record

SWAP PIP

      





This symbol is used to indicate safety instructions

or to draw your attention to specic hazards

and risks.



This symbol is used to indicate additional

information or important notes.

  

•Replacement Remote Control

•2xAAA Batteries

•This operating instructions incl. Code List

  

•Donot use the Universal Remote Control in

moist or wet environments and avoid spray-

water contact.

•Donot expose the Universal Remote Control

to heat sources or direct sunlight.

•Donot drop the Universal Remote Control.

•Never open the Universal Remote Control. It

contains no user-serviceable parts.

•Aswith allelectrical devices, keep the

Universal Remote Control away from

children.



•When inserting batteries, note the

correct polarity (+ and -markings) and

insert the batteries accordingly.Failureto

do so could result in the batteries leaking

or exploding.

•Donot short-circuit batteries.

•Donot charge batteries.

•Donot throw batteries in are.

•Keep batteries out of the reach of

children.

•Donot allow children to change batteries

without supervision.

•Remove the batteries from products

that arenot being used for an extended

period.

     



•Use 2AAA batteries

•Remove the battery cover from bottom

of remote.

•Check the +/- polarity on the batteries

and inside the compartment.

•Insert the batteries.

•Slide the battery holder back into the

remote until the clips locate.

   

This remote control saves the settings during

battery change.

 

This remote control can by default control 90%

models of SAMSUNG brand, there´s no need to

set it up. lf it doesn‘t work, please choose one

of the following setup methods 5.1 or 5.2.

  

 

       

       

       

       

       

       

        

1. Press and hold the key [MUTE] and

[POWER] until the LED will be lit,

then release keys.

2. Enter the three codes from code Iist.

When the code input is nished, the

LED will turn off.

3. Please try to use the remote control.

lf it doesn‘t work well, please try other

codes: [002], [003], [004] ...



lf the code is invalid, the LED ashes twice

and then lights up permanently.Toexit the

setup, please press [MUTE].

  

1. Press and hold the key [MUTE] and

[POWER] until the LED will be lit, then

release keys.

2. Press the key [CH+]. Each time you

press, the remote will search once.

When the code changes, you can test

if [POWER], [VOL+],[MENU],[0-9] keys

work well. If ok ,please press [MUTE] to

save the code and exit.

3. lf it doesn‘t work well, repeat the fast

search by pressing [CH+].

  

Use the following method to nd out which

code is currently set:

1. Press and hold [MUTE], then press

[POWER] until the LED will be lit, then

release keys.

2. Input [9].[9].[0] with number keys. The

LED will ash twice and goes off.

3. Press the number key 1for the 1st digit

of the code. The LED will start to ash.

Count the LED ashes. The number of

ashes resemble the code‘s rst digit.

Repeat this procedurefor the 2nd and

3rddigit of the code:

2nd digit -> enter 2->count LED

ashes

3rddigit -> enter 3->count LED ashes

lf code number is [0] the LED will not

ash.

    

Due to too many Remote Control models, we

only Iist some of them below.

lf your remote control is similar to the drawing,

the replacement remote can control your TV

(Page 74).

    

Press and hold the [RETURN] and [0] buttons for

about 5seconds until the status LED flashes three

times and then goes out. The remote control is

now successfully reset to the factory settings.



All keys with learnt codes or all copied keys,

as well as all remote control settings will

be deleted.

  

This remote control is equipped with alearning

function. Thus, you could learn functions of

your original remote to this remote control.

    

•The batteries in the two remote controls

have to be in good condition. Replace them

if necessary.

•Place the remote controls with the infrared

diodes so that they point towards each

other.

•Wherenecessary adjust the height of both

remotes so that infrared diodes areproperly

aligned.

•The distance between the remote controls

should be about 3cm.



•Donot move the remote controls during

the learning procedure.

•E

nsur

et

hat

the

ro

om

is

not

lit

by

uor

escents

tubes

or

low

ener

gy

consumption lamps since such light

sources could interferewith the copying.

•The 2remotecontrols must be at least

1meter away from any light source.

•During learning mode, if no key is

selected for morethan 15 seconds, the

learning mode will exit automatically or

if no other remote signal is received.

•Each function key will hold only one

command. Anew command to be learned

will automatically replace the previous one.

   

1. Press and hold the [MUTE] and [VOL+]

keys for approx. 5seconds until the LED

will be lit.

5

2. Enter the code [9] [8] [0], the LED will ash

2times and then remain on.

3. The remote control is now ready to learn

new commands.

   

1. Press and release the desired key on the

original remote control which you want the

command to be learned. The LED at your

replacement remote will ash to conrm

that the information has been received.

ca. 3cm

ORIGINAL


