HANDLEIDING EIGENAAR

AUTO STEREO FM - RDS / BLUETOOTH / MP3 MET

USB-HOST / SD-SLEUF / AUX-INGANG

BILSTEREO FM - RDS / BLUETOOTH / MP3

MED USB VÄRD / SD SPÅR / AUX. INEFFEKT

KÖPARENS BRUKSANVISNING

English (P.1 - P.3)

Deutsch (P.3 - P.5)

Dansk (P.5 - P.7)

P.1

GENERAL OPERATION

English

1. POWER ON/OFF

Press this button to turn on the unit. To turn off, press this button more than 1 second.

2. BAND SELECTOR / PAUSE

a) Each time this button is pressed, the radio band is changed.

b) Press this button to pause the track during playback.

3. AUTO-STORE/PRE-SCAN BUTTON / REPEAT

a) Press this button more than 2 seconds, it searches all station frequencies upward and memorize automatically

to the 6 preset stations by catching the frequency. Press this button shortly, it re-calls the memorized station

frequencies (1-6) automatically every 5 seconds.

b) Press this button to repeat the track during playback.

4. LCD DIGITAL DISPLAY

5. DISPLAY BUTTON

This button serves to show available information.

7. PANEL RELEASE

This button is used to release the panel from the unit.

9. RDS (RADIO DATA SYSTEM)

You can enjoy RDS advantage on FM radio as follows:

lProgram Service Name (PS) : When RDS station is received, station's name will appear on the display.

lTraffic Program (TP) : When station with traffic program is received, “TP” indicator will appear on the display.

lWhen RDS is on, the unit will continue checking the signal of alternative frequencies from time to time. If the new

alternative frequency is stronger than current one, it automatically switch to the new frequency. When RDS is

flashing, the alternative frequency is searching but RDS signal is not received.

lEnhanced Other Networks (EON): When tune to a station which is linked to others by EON, the radio is capable of

receiving Traffic Announcement from the linked stations.

10. TA (TRAFFIC ANNOUNCEMENT) / PTY (PROGRAMME TYPE NAME)

a) Press this button shortly to select TA mode. When TA mode is on, it is able to receive traffic announcements or

stations with Traffic Program (TP). It works as follows: lIf the volume is low, it will be raised temporarily and will

back to original volume level after traffic announcement. lIf the radio is mute, it will be de-muted during traffic

announcement.

b) There are 2 series of programme type (PTY) available for PTY search tuning when you press the button for

longer than 1 second and then pressing any Station Preset Button (1-6) until the desired PTY code appears on

the display. The radio will stop on station transmitting the selected PTY code. Next PTY searching can be

activated by repeating the same procedure. During programme type searching, PTY button can be pressed to

stop searching and the radio will back to the original station. “PTY NONE” will appear on the display if the

selected PTY code is not receivable.

11. ANSWERING BUTTON FOR INCOMING CALLS

12. VOLUME/SELECTION (“VOL/SEL”)

a)Rotate this button clockwise to increase volume level and vice versa.

b)Press this button shortly to show Volume/Bass/Treble/Balance/Fader control. Then, rotate clockwise to

increase setting level and vice versa.

c)By pressing more than 2 seconds, it activates the selection mode in cyclical position and change the

setting by rotating the knob.

l BEEP ON / BEEP OFF (not available)

LOCATION OF CONTROLS TASTENBELEGUNG KNAPPER OG KO NTROLLER

SITUACIÓN DE LO S CO NTROLES LOCALIZAÇÃO DOS CO MANDOS PLACERING AV KONTROLLER

PLAATS VAN DE BED IENINGSELEMENTEN LAITTEEN SÄÄ TIMET

Español (P.8 - P.10)

Português (P.10 - P.12)

Svenska (P.12 - P.14)

Nederlands (P.14 - P.17)

Suomi (P.17 - P.19)

CAR STEREO FM - RDS / BLUETOOTH / MP3

WITH USB HOST / SD SLOT / AUX. INPUT

OWNER'S MANUAL

AUTORADIO UKW - RDS / BLUETOOTH / MP3

MIT USB-HOST / SD-SCHLITZ / AUX-EINGANG

BEDIENUNGSANLEITUNG

BILSTEREO MED FM RDS / BLUETOOTH / MP3

USB-TERMINAL / SD KORTLÆSER / AUX-TERMINAL

BETJENINGSVEJLEDNING

EQUIPO ESTÉREO FM - RDS / BLUETOOTH / MP3 PARA AUTOMÓVIL

CON ENTRADA AUX. / PUERTO USB / LECTOR SD

MANUAL DEL PROPIETARIO

ESTÉREO FM - RDS / BLUETOOTH / MP3 PARA CARRO

COM USB ANFITRIÃO / ENTRADA SD / AUX. ENTRADA

MANUAL DO PROPRIETÁRIO

KÄYTTÖOHJE

AUTOSTEREO FM - RDS / BLUETOOTHIN / MP3 JOSSA

USB-LIITÄNTÄ / SD-LUKIJA / AUX-LIITÄNTÄ

CAU-430BT

MP3

INPUT

AUX

MIC

SD

SCAN

AMS

BND MOD

RPT

MUTE

105

6

+10

T/P

RESET

MP3

INPUT

AUX

MIC

SD

(16)

(3) (8)(2) (13) (4)(7) (1)

(17)(20) (18)

(19)

(12)(5) (6)

(15)

(9)(10)

(11)

(14)

(20)

6. SCAN CONTROL

Press this button to scan the receivable FM stations during radio mode. When receivable stations are tuned in,

they are monitored for approximately 5 seconds before advancing to the next receivable station. Press this button

once again to stop scanning as desired.

8. MODE / MUTE

a) Briefly press this button to select Radio (TUNER), USB (USB-DRIV), SD (MEM-CARD), Auxiliary Input (AUX) or

A2DP (BT-PLAY) mode.

b) When pressing the button for more than 2 seconds, it will mute volume control.

SETTING CLOCK TIME MANUALLY

a) Press the button to show “XX’XX” and hold it until the display flash and release.

b) Rotate “VOL/SEL” button clockwise to set HOUR and anti-clockwise to set MINUTE.

13/14. MANUAL UP/DOWN TUNING / TRACK SEEK UP/DOWN

On radio mode, pressing this button more than 2 seconds, it will tune one frequency step higher or lower.

On USB/SD mode, pressing this button shortly will move to the one track higher or lower. Pressing more

than 2 seconds, it will move fast forward or backward to a specific position.
