Wireless battery operated doorbell

Art.no 36-7285 Model 98203 battery

Please read theentire instruction manual before use and then save it for future

reference. We reserve theright for any errors in text or images and any necessary

changes made to technical data. In theevent of technical problems or other

queries, please contact our Customer Services.

Safety

• Never subject theproduct to high temperatures, damp or dusty environments,

heavy vibrations or impacts.

• Theindoor unit must not be exposed to rain or moisture.

• Thebattery should be removed if theproduct is not to be used for anextended

period, otherwise thebattery might leak and damage theproduct. Never leave

discharged batteries in thebattery compartment.

• Never try to repair theproduct, dismantle or modify it in any way.

Buttons and functions

Transmitter

1. Doorbell/receiver

2. Button to select thevolume

3. LED indicator

4. Transmitter

5. Push Button Ring Signal

Installation

Handy tip:

• 1 transmitter is included but you may also connect anadditional 7 transmitters

(sold separately).

• If you are connecting several transmitters to thedoorbell, set different signals

for each transmitter so you know at which door thesignal is coming from.

Battery/pairing theunits

1. Open thetransmitter carefully

by pressing thelatch with

ascrewdriver.

2. Remove theplastic tab from

thebattery holder to activate

thebattery in theremote control.

3. Remove thebattery cover from

theback of thedoorbell.

4. Observe themarkings on

thebottom of thebattery

compartment and insert

2×AA/LR6 batteries.

Thedoorbell will sound twice

and theLED indicator (3) starts

to flash which indicates that

thedoorbell is ready to be paired

with thetransmitter.

5. Within 30 seconds,

press thetransmitter

that you want to

connect thedoorbell

to. Thedoorbell

will sound when

thepairing has been

successful.

6. If you wish to pair another transmitter, take out

thebatteries from thedoorbell and cut off thepower

supply. Then repeat steps 4−5.

7. Replace thebattery cover on thedoorbell.

Choosing thering signal

Once thepairing has been successful, choose thering

signal by pressing repeatedly on thebutton inside

thetransmitter. You can choose between atotal of

16 different melodies and sounds:

1. Dingdong

2. Für Elise

3. Westminster Chimes

4. TheButterfly Lovers

5. Swan Lake

6. Red River Valley

7. My heart will go on

8. Turkish March

9. Menuet

10. Congratulations

11. William Tell Overture

12. Romance of love

13. Memory

14. TheLittle Mermaid

15. Greensleeves

16. Romeo & Juliet

Selecting thevolume

Press thebutton to select thevolume.

You can choose between high and low

volume.

Assembly

Information

• Avoid placing theunits next to metal objects such as metal window frames as

this may cause interference with reception.

• Test thedoorbell’s functionality/location before final mounting.

1. Screw on

or glue (with

double-sided

adhesive tape)

thebackplate

of the

transmitter to

thewall.

Doorbell

Attach ascrew to thewall and hang up thedoorbell on

thewall bracket.

Remove thepaired transmitter

Information

If you follow thefollowing steps, it will remove all thepaired

transmitters from thedoorbell’s memory.

1. Dismantle one of thetransmitters.

2. Remove thepower supply to thedoorbell by removing thebatteries. Wait afew

seconds and insert thebatteries again so that thedoorbell is in pairing mode.

Thedoorbell will sound twice.

3. While thedoorbell is in pairing mode, press thebutton inside thetransmitter.

Thedoorbell will sound to confirm that all thetransmitters have been removed

from thedoorbell’s memory.

Care and maintenance

Clean theproduct using adamp cloth. Use only mild cleaning agents, never solvents

or corrosive chemicals.

Troubleshooting

No sound when

thepush button

is pressed.

• Check that thebatteries are inserted correctly and that

they are not flat.

• Excessive distance between thetransmitter and thedoorbell.

Responsible disposal

This symbol indicates that this product should not be disposed of

with general household waste. This applies throughout theentire EU.

In order to prevent any harm to theenvironment or health hazards

caused by incorrect waste disposal, theproduct must be handed in

for recycling so that thematerial can be disposed of in aresponsible

manner. When recycling theproduct, take it to your local collection

facility or contact theplace of purchase. They will ensure that

theproduct is disposed of in anenvironmentally sound manner.

Specifications

Doorbell (receiver)

Batteries 2×AA/LR6 batteries (sold separately)

Power consumption ≤ 0.5 W

Range Up to 100 m (clear line of sight)

Noise level 78 dB (at adistance of 1 m)

Signals 16 different melodies and sounds

Size 70×70×27 mm

Push button (transmitter)

Transmission frequency 433.92 MHz

Battery CR2032 lithium (3 V)

Size 35×17×85 mm

2. Fit the

transmitter

onto the

backplate,

making

sure that

thegasket is

in place. Press

thelatch on

thetransmitter

until it clicks

into place.
