Power Bank

Art. no 39-1288

Please read theentire instruction manual before using theproduct and

then save it for future reference. We reserve theright for any errors in text

or images and any necessary changes made to technical data. In theevent

of technical problems or other queries, please contact our Customer

Services.

Safety

• Never subject theproduct to direct sunlight, high temperatures,

dusty environments or heavy vibrations.

• Do not use theproduct if it or its mains lead/charging lead is

damaged in any way.

• The product must not be taken apart or modified.

• Do not use theproduct in anarea where flammable liquids or gases

are used or stored.

• Never expose theproduct to impacts, shocks, rain, liquids

or moisture.

• Make sure that theproduct is stored out of thereach of children.

The product may only be charged via aUSB port.

Informaon

This Power Bank is USB-IF certified and supports USB-C Power Delivery

(USB-C port). Power Delivery means that most of thelatest smartphones

can be quick-charged with 5, 9 or 12 V depending on themodel. The

USB-A port does not support quick-charging to thesame degree and

can only deliver anoutput of max 5 V/1.5 A *.

The included USB cable is intended for use with theUSB-C port.

For charging via theUSB-A port, thecharging cable of theexternal

device should be used.

*Since this product has been USB-IF certified it is not possible to have

aQuick Charge function on theUSB-A port (Quick Charge is outside

thescope of USB-IF certification).

Buttons and functions

Care and maintenance

• Clean thepower bank by wiping it with adamp cloth. Use only mild

cleaning agents, never solvents or corrosive chemicals.

• If thepower bank is not to be used for along time, thebattery should

be charged every three months to keep it in good condition. Store

thepower bank indoors, in adry, dust-free place out of children’s reach.

Responsible disposal

1. On/off button

2. USB-A output port

3. USB-C input/output port

4. LED indicator (% battery capacity)

Charging thepower bank

1. Connect theincluded charging lead to theUSB-C port (3) and

to aPD charger. (PD=Power Delivery).

2. The charging status can be checked using theLCD indicator (4).

Informaon

In order to be able to charge your power bank as quickly as possible you

should use aUSB-C PD charger (PD=Power Delivery). It takes about 2.5

hours to charge afully discharged power bank using a18 W PD charger.

If you use aUSB-A charger (5V/1.5A) with aUSB-A to USB-C cable it will

take 4.5 hours.

Charging external devices

1. Connect theincluded charging cable

or thecharging cable of thedevice

to be charged to one of theUSB

ports (2 or 3). You may for instance

use theUSB-C PD port to charge

your laptop or another device and

use theUSB-A port to charge your

smartphone at thesame time.

2. If charging does not begin automatically,

press the on/off button (1) to begin

the charging process. The LED

indicator will light up for amoment to

show thecharge status of thepower

bank.

This symbol indicates that theproduct should not be

disposed of with general household waste. This applies

throughout theentire EU. In order to prevent any harm to

theenvironment or health hazards caused by incorrect

waste disposal, theproduct must be handed in for

recycling so that thematerial can be disposed of in

aresponsible manner. When recycling your product, take

it to your local collection facility or contact theplace of

purchase. They will ensure that theproduct is disposed of

in anenvironmentally sound manner.

Specifications

Capacity 10000 mAh (max 18 W)

Power bank in/out USB-C 5 V/3 A, 9 V/2 A, 12 V/1.5 A

Power bank out USB-A 5 V/1.5 A

Size 156×68×17mm

Weight 230g

Operang temperature 0–45 °C

Capacity LED 1 LED 2 LED 3 LED 4

75–100% Steady glow Steady glow Steady glow Steady glow

50–75% Steady glow Steady glow Steady glow Off

25–50% Steady glow Steady glow Off Off

10–25% Steady glow Off Off Off

0–10% Flashing Off Off Off
