SPECIAL SAFETY RULES

CUTTING PROCEDURES

DANGER

Keep hands away from cutting area and the blade.

Keep your second hand on auxiliary handle, or

motor housing. If both hands are holding the saw, they

cannot be cut by the blade.

■ Do not reach underneath the workpiece. The guard

cannot protect you from the blade below the workpiece.

■ Adjust the cutting depth to the thickness of the

workpiece. Less than a full tooth of the blade teeth

should be visible below the workpiece.

■ Never hold piece being cut in your hands or across

your leg. Secure the workpiece to a stable platform.

It is important to support the work properly to minimize

body exposure, blade binding, or loss of control.

■ Hold the power tool by insulated gripping surfaces

only, when performing an operation where the

cutting tool may contact hidden wiring or its own

cord. Contact with a “live” wire will also make exposed

metal parts of the power tool “live” and could give the

operator an electric shock.

■ When ripping, always use a rip fence or straight

edge guide. This improves the accuracy of cut and

reduces the chance of blade binding.

■ Always use blades with correct size and shape

(diamond versus round) of arbour holes. Blades that

do not match the mounting hardware of the saw will run

eccentrically, causing loss of control. Use only blades

specified in this manual, complying with EN 847-1.

■ Never use damaged or incorrect blade washers

or bolt. The blade washers and bolt were specially

designed for your saw, for optimum performance and

safety of operation.

KICKBACK CAUSES AND RELATED WARNINGS:

■ kickback is a sudden reaction to a pinched, bound or

misaligned saw blade, causing an uncontrolled saw to

lift up and out of the workpiece toward the operator;

■ when the blade is pinched or bound tightly by the kerf

closing down, the blade stalls and the motor reaction

drives the unit rapidly back toward the operator;

■ if the blade becomes twisted or misaligned in the cut,

the teeth at the back edge of the blade can dig into the

top surface of the wood causing the blade to climb out

of the kerf and jump back toward the operator.

Kickback is the result of saw misuse and/or incorrect

operating procedures or conditions and can be avoided by

taking proper precautions as given below.

■ Maintain a firm grip with both hands on the saw

and position your arms to resist kickback forces.

Position your body to either side of the blade, but

not in line with the blade. Kickback could cause the

saw to jump backwards, but kickback forces can be

controlled by the operator, if proper precautions are

taken.

■ When blade is binding, or when interrupting a cut

for any reason, release the trigger and hold the saw

motionless in the material until the blade comes

to a complete stop. Never attempt to remove the

saw from the work or pull the saw backward while

the blade is in motion or kickback may occur.

Investigate and take corrective actions to eliminate the

cause of blade binding.

■ When restarting a saw in the workpiece, centre the

saw blade in the kerf and check that saw teeth are

not engaged into the material. If saw blade is binding,

it may walk up or kickback from the workpiece as the

saw is restarted.

■ Support large panels to minimise the risk of blade

pinching and kickback. Large panels tend to sag

under their own weight. Supports must be placed under

the panel on both sides, near the line of cut and near

the edge of the panel.

■ Do not use dull or damaged blades. Unsharpened

or improperly set blades produce narrow kerf causing

excessive friction, blade binding and kickback.

■ Blade depth and bevel adjusting locking levers

must be tight and secure before making cut. If blade

adjustment shifts while cutting, it may cause binding

and kickback.

■ Use extra caution when sawing into existing walls

or other blind areas. The protruding blade may cut

objects that can cause kickback.

LOWER GUARD FUNCTION

■ Check lower guard for proper closing before each

use. Do not operate the saw if lower guard does not

move freely and close instantly. Never clamp or

tie the lower guard into the open position. If saw is

accidentally dropped, lower guard may be bent. Raise

the lower guard with the retracting handle and make

sure it moves freely and does not touch the blade or any

other part, in all angles and depths of cut.

■ Check the operation of the lower guard spring. If

the guard and the spring are not operating properly,

they must be serviced before use. Lower guard may

operate sluggishly due to damaged parts, gummy

deposits, or a build-up of debris.

■ Lower guard may be retracted manually only for

special cuts such as “plunge cuts” and “compound

cuts”. Raise lower guard by retracting handle and

as soon as blade enters the material, the lower

guard must be released. For all other sawing, the

lower guard should operate automatically.

■ Always observe that the lower guard is covering the
