Käyttöohje Olympus VN-6500PC Äänitallennin

Käyttöohje

6

EN

8

6

15m15s 14m25s

1 2

7

Erase: Start

File Erase!

9

Erase: Cancel

All Erase!

Erase Done

Remote

PC

PC

1

2

3

p

15m15s 14m15s

1

4

5

5

15m15s 14m15s

15m15s 14m15s

Remain 22h52m46s

1

342

3

Time & Date

1. 1‘08

12:00

AM

1. 1‘08

12:00

AM

7.25‘08

3:00

PM

6

1

1

• This manual is a basic version. Please

refer to the complete advanced

manual either from the stored data

in the [OL_MANUAL] folder of the

recorder or download the data from

the OLYMPUS website.

• The contents of this document

may be changed in the future

without advanced notice. Contact

our Customer Support Center for

the latest information relating

to product names and model

numbers.

• The utmost care has been taken to

ensure the integrity of the contents

of this document. In the unlikely

event that a questionable item,

error, or omission is found, please

contact our Customer Support

Center.

• Any liability for passive damages or

damage of any kind occurred due to

data loss incurred by a defect of the

product, repair performed by the

third party other than Olympus or an

Olympus authorized service station,

or any other reason is excluded.

Trademarks and registered trademarks:

• Microsoft, Windows

and Windows Media

are registered

trademarks of

Microsoft Corporation.

• Macintosh is the trademark of Apple

Inc.

Safe and Proper Usage

Before using your new recorder,

read this manual carefully to ensure

that you know how to operate it

safely and correctly. Keep this

manual in an easily accessible

location for future reference.

• The warning symbols indicate

important safety related

information. To protect yourself

and others from personal injury or

damage to property, it is essential

that you always read the warnings

and information provided.

Getting Started

Identification of Parts

1 Built-in Microphone

2

MIC

(Microphone) jack

3

HOLD

switch

4 USB terminal

5

STOP

(4 ) button

6

PLAY

/

OK

(`) button

7 0 (Rewind) button

8 Battery cover

9

FOLDER

/

INDEX

button

0

EAR

(Earphone) jack

! Display (LCD panel)

@ Record/play indicator light

#

REC

(s ) button

$

+

button

% 9 (Fast Forward) button

^

–

button

&

DISP

/

MENU

button

*

ERASE

(s ) button

( Strap hole

• Strap is not supplied. Use the

optional accessory.

Display (LCD panel):

1 Folder indicator

2 [

] Microphone sensitivity

indicator

[

] LowCut filter indicator *

[

] Variable Control Voice

Actuator indicator

[

] Record mode indicator

[K] Fast playback indicator

[J] Slow playback indicator

[

] Segment repeat playback

indicator*

3 Guide indicator

4 Character information display

Recording level meter

5 Battery indicator

6 Erase lock indicator

7 Current file number

*

For VN-6500PC only.

Inserting Batteries (Fig. 1)

1 Lightly press down on the arrow and

slide the battery cover open.

2 Insert two size-AAA alkaline batter-

ies, observing the correct polarity.

3 Close the battery cover completely.

• When the HOLD switch is set to

the direction of the arrow, the

display is turned off after [HOLD]

is displayed. Follow the next step

without regard to it.

An optional Ni-MH Rechargeable

Battery (BR401) from Olympus can

be used for the recorder.

Replacing Batteries:

When [N] appears on the display,

replace the batteries as soon as

possible. Size-AAA alkaline batteries

are recommended. When the batteries

are depleted, [O] appears on the

display, and the recorder shuts off.

• To replace the battery, make sure

that you set the HOLD switch to

the opposite direction of the arrow

before replacing.

Power Supply (Fig. 2)

Power on:

Slide the

HOLD

switch in the direction op-

posite that indicated by the arrow.

Power off:

Slide the

HOLD

switch in the direction

indicated by the arrow while the recorder is

not in operation.

Standby Mode and Display Shut Off:

If the recorder is stopped for 5 minutes

or longer during recording or playing,

it goes into Standby (power-save)

mode, and the display shuts off. To exit

Standby mode and turn on the display,

press any button.

Setting Time and Date [TIME] (Fig.

3

)

When you install batteries for

the first time or each time you

replace the batteries, the “Month”

indication will flash. In such a case,

be sure to set the time and date

by following steps 4 through 6

described below.

1 Press and hold the

DISP

/

MENU

button for 1 second or longer to the

main menu.

2 Press the 9 or 0 button to

select [

Sub Menu

].

Introduction

EN
