Käyttöohje Hoover TSP2020 011 Spirit Pölynimuri

Käyttöohje

2

GB

(*Certain Models Only)

USING YOUR CLEANER

1. Extract power cord and plug it into the power supply. Do not pull the cord beyond the

red marker. [5]

2. Adjust the telescopic tube* to the desired height by moving the telescopic tube

adjuster* up and raise or lower the hose handle to the most comfortable cleaning

position. [6]

3. Select the type of surface to be cleaned by pressing the pedal in the nozzle. [7]

Hard Floor – Brushes are lowered to protect the floor.

Carpet – Brushes are raised for the deepest clean.

4. Switch the cleaner on by sliding the On-Off control to the ON position. [8]

5. Adjust the power level by further sliding the On-Off / variable power control* slider on

cleaner mainbody. [9]

6. Switch off at the end of use by sliding the On-Off control to the OFF position. Unplug

and press the carry handle/cord rewind button to wind the power cord back into the

cleaner. [10]

7. To store your cleaner adjust telescopic tube* to the lowest height setting and park the

nozzle in the park position on the cleaner main body. [11]

CLEANER MAINTENANCE

Emptying the Dust Container

When the dust reaches the max level indicator in the container, empty the dust container.

IMPORTANT: To maintain optimum performance do not allow the dust to sit higher than

the max level.

1. Release the Dust Container by pressing the Dust Container Release Button. Lift the

Dust Container from the cleaner mainbody. [14]

2. Hold the Dust Container over a bin with one hand, and remove the Dust container lid

by rotating anti-clockwise. [15]

3. Empty the dust from the bin. [16]

4. Close and refit the dust container to the cleaner.

Cleaning the washable filters

The cleaner is fitted with pre motor filter and exhaust filter. To maintain optimum cleaning

performance, regularly remove the filter and tap against the side of the bin to release

dust.

The filters should be washed every 5 container empties or when the filter has excessive

dust level.

IMPORTANT: All bagless cleaners require regular filter cleaning. Failure to clean your

filters may result in air blockage, overheating and product failure. This may invalidate

your guarantee.

IMPORTANT: Regularly check and maintain the filters.

IMPORTANT: Always ensure the filter pack is fully dry before use.

To access the Pre-Motor filter:

1. Remove the dust Container from the cleaner mainbody. [14]

2. Hold the Dust Container over a bin with one hand, and remove the bin lid by rotating

anti-clockwise. [15]

3. Remove the filter mesh* by rotating clockwise from bin lid. [17]

4. Remove the pre-motor filter by rotating clockwise from bin lid. [18]

5. Gently tap and wash the filter mesh* and filter, do not use hot water or detergents.

[19] Remove excess water from the filter mesh* and filter and leave to dry fully before

re-using. [22]

6. Reassemble the pre-motor filter pack (filter mesh* and filter) once fully dry and refit to

the cleaner.

ACCESSORIES AND NOZZLES

All accessories can be fitted to the end of the handle or the end of the tube.

2 in 1 Accessory

Remove the 2in1 accessory from the rear of the cleaner [12] and fit onto the end of the

handle. [13]

Crevice Tool – For corners and hard to reach areas. [1U]

Dusting Brush – For bookshelves, frames, keyboards and other delicate areas. To extend

the brushes push the button on the body of the tool. [1U]

Pet Hair Remover Mini Turbo Nozzle* - Use the mini turbo nozzle on stairs or for deep

cleaning on textile surfaces and other hard to clean areas. Particularly suitable for pet hairs

removal. [1V]

Allergen Remover Mini Turbo Nozzle* – Use the mini turbo nozzle on stairs or for deep

cleaning on textile surfaces and other hard to clean areas, particularly suitable for allergen

removal. [1W]

Grand Turbo Nozzle* –

Use the turbo nozzle for deep cleaning on carpets. [1X]

Hard Floor Caresse Nozzle – For parquet floors and other delicate floors.

[1Y]

IMPORTANT: Do not use the Grand turbo and mini turbo nozzles on rugs with long fringes,

animal hides and carpet pile deeper than 15mm. Do not keep the nozzle stationary while

the brush is rotating.

Spirit_Manual ML IM.indd 2 4/5/2011 11:07:14 AM
