2

*Certain Models Only **Nozzle design may vary according to models

GETTING TO KNOW YOUR CLEANER

GB

A. Bag Door Release Latch

B. Cord Rewind Button

C. Exhaust Filter Cover

D. On/Off Button

E. Variable Power Control*

F. Bag Check Indicator

G. Bag Door

H. Main Cleaner

I. Hose

J. Hose Handle

K. Suction Regulator*

L. Telescopic Tube*

M. Telescopic Tube Adjustor*

N. Tool holder

O. Floor Type Selector*

P. Carpet and Floor Nozzle (GP) **

P1. Carpet Nozzle (CA) **

P2. Hard Floor Nozzle (HF) **

Q. Exhaust Filter

R. Pre-motor Filter Frame

S. Pre-motor Filter

T. Accessories

T1. Crevice Tool

T2. Dusting Brush

U. Pet Hair Remover Mini Turbo Nozzle*

V. Allergy Remover Mini Turbo Nozzle*

W. Parquet Extra Nozzle*

X. Parquet Nozzle*

GETTING TO KNOW YOUR CLEANER

Remove all components from the packaging.

1. Connect the hose to the cleaner main body, ensuring it locks into position. [1] To

release the hose: rotate the connector counter clockwise and pull it.

2. Connect the hose handle to the upper telescopic tube end [2A] and store the

accessories on the tube [3B].

3. Connect the tube lower end to carpet and oor nozzle**[3A].

USING YOUR CLEANER

1. Extract power cord and plug it into the power supply. Do not pull the cord beyond

the red marker [

5].

2.

Adjust the telescopic tube* to the desired height by moving the telescopic tube adjustor

up and raise or lower the handle to the most comfortable cleaning position [4].

3. Carpet and Floor Nozzle**: Press the oor type selector pedal* on the nozzle to

select the ideal cleaning mode for the oor type [6].

Hard Floor – Brushes are lowered to protect the oor.

Carpet – Brushes are raised for the deepest clean.

4.

Switch the cleaner on by pressing the On/Off button on the cleaner main body. [6]

5. Slide Variable power control to increase or decrease the power.

[7]

6. Adjust the suction regulator to the desired level.

[8]

7. Switch off at the end of use by pressing the on/off button. Unplug and press the cord

rewind button to wind the power cord back into the cleaner.

8. Parking and storage – The tube can be parked for temporary storage while in use, or in the

storage position when not in use. [9]

CLEANER MAINTENANCE

Replacing the Dust Bag

If the bag check indicator is red, please check and, if necessary, replace the bag.

1. Lift the bag door Latch to open the bag door and remove the bag [10]. The full dust

bag should be disposed of correctly and carefully.

2. Fold a new bag as shown on the bag and t by inserting the collar into the bag

holder. [11]

3. Close the Bag door.

REMEMBER: The bag check indicator may be red if an obstruction has occurred. In this

case refer to ‘Removing a Blockage From the System’.

Cleaning the Filter:

To maintain optimum performance of your cleaner, please wash the pre-motor lter and

exhaust lter after each 5 bag changes.

Cleaning the pre-motor lter:

1. Lift the bag door release latch to open the bag door and remove the bag.

[10]

2. To remove the pre-motor lter slide the pre-motor lter frame from the cleaner. [12]

3. Remove the lter from the holder. [12]

4. Wash it in hand warm water [15], and allow it to dry [16] thoroughly before replacing

to the cleaner [12].

Cleaning the exhaust lter:

1. The remove the exhaust lter, unclip the exhaust lter cover and remove the exhaust

lter pack. [13,14]

2. Wash the lter in hand warm water [15] and allow it t

o dr

y [16] thoroughly before

replacing to the cleaner. [14

]

REMEMBER: Do not use hot water or detergents. In the unlikely event of the

lters becoming damaged, t a Genuine Hoover replacement. Do not try and

use the product without a dust bag or lter tted.

Cleaning the permanent cloth dust bag* (certain models only)

To maintain optimum performance we recommend that you wash the permanent cloth

dust bag under hand warm water after every 5 full bags. Remove excess water and leave

to dry fully before replacing.

Removing a blockage from the system

If the bag check indicator is red:

1. Check if the bag is full. If so refer to ‘Replacing The Dust Bag’.

2. If it is not full, then;

A.

Do the lters need cleaning?

If so refer to ‘Cleaning the Filter’.

B. Check if there is any other blockage in the system - Use a rod or a pole to

remove any blockage from

telescopic tube* or exible hose.
