Installing a domestic appliance can be a complicated operation which if not carried out correctly, can seriously affect consumer

safety. It is for this reason that the task should be undertaken by a professionally qualified person who will carry it out in

accordance with the technical regulations in force. In the event that this advice is ignored and the installation is carried out

by an unqualified person, the manufacturer declines all responsibility for any technical failure of the product whether or not

it results in damage to goods or injury to individuals.

2 GB

BUILT-IN

The furniture in which your hob will be installed and all adjacent

furniture, should be made from materials that can withstand high

temperatures. In addition, all decorative laminates should be fixed

with heat-resistant glue.

Installation:

• A watertight seal is supplied with the hob.

Before fitting:

- turn the hob upside down, with the glass surface facing downwards.

Make sure the glass is protected.

- fit the seal round the hob.

- make sure that it is correctly fitted to avoid any leakage into the

supporting cabinet.

• It it important to fit the hob on a level supporting surface.

• Deformations caused by incorrect fitting can alter the specifications

of the worktop and the performance of the hob.

• Leave a gap of at least 5 cm between the appliance and any

neighbouring vertical surfaces.

• It is absolutely essential that the recess conforms with the

dimensions indicated.

•You can not build the hob in above an oven with no fan, a

dishwasher, fridge, freezer or washing machine.

INSTALLATION

• The yellow/green wire of the power supply cable must be

connected to the earth of both power supply and appliance

terminals.

• The manufacturer cannot be held responsible for any accidents

resulting from the use of an appliance which is not connected

to earth, or with a faulty earth connection continuity.

• Any queries regarding the power supply cord should be referred

to After Sales Service or a qualified technician.

"The installation must conform to the standard directives."

The manufacturer declines all responsibility for any damage that

may be caused by unsuitable or unreasonable use.

Warning :

• Always check before any electrical operation, the supply tension

shown on the electricity meter, the adjustment of the circuit-

breaker, the continuity of the connection to earth to the installation

and that the fuse is suitable.

• The electrical connection to the installation should be made via

a socket with a plug with earth, or via an omnipole cut-out switch

with an opening gap of at least 3 mm.

If the appliance has a socket outlet, it must be installed so that

the socket outlet is accessible.

ELECTRICAL CONNECTION

• Cut a hole in the worktop of the dimension shown in the

diagram below.A minimum of 50 mm space should be left

around the hole.

• The worktop should be at least 30 mm thick and made of

heat-resistant material.As shown in the Figure(1)

• It is essential that the induction hob is well ventilated and

that the air intake and exit are not blocked.

Make sure the hob is correctly installed as shown in Figure(2)

JIKI D HJ

JIKI D JJ

JIKI B HJ

A`i `ekXb\

A`i \o`k

NB: For safety, the gap between the hob and any cupboard

above it should be at least 760mm.

Connection to power supply

The socket shall be connected in compliance with the relevant

standard, to a single-pole circuit breaker. The method of

connection is shown in Figure(3):

Seal

The cable must not be bent or compressed.

be carried out the by sale agent with dedicated tools to avoid

any accident.

• I f the cable is damaged or to be replaced, the operation must

Grey

L1 L2

N1 N2
