Käyttöohje

4

Assembly see page 31

Fault Cause Remedy

Insufficient water - Supply pressure inadequate - Check water pressure (If a pump has been installed

check to see if the pump is working).

- Filters are dirty (97973000) - Clean filter in front of the mixer and on the MTC-

thermo cartridge (97973000)

- filter insert shower dirty - Clean filter insert between shower and hose

Crossflow, hot water being forced into cold water pipe,

or vice versa, when mixer is closed

- Backflow preventers dirty or leaking - Clean backflow preventers, exchange if necessary

Spout temperature does not correspond with tempera-

ture set

- Thermostat has not been adjusted - Adjust thermostat

- Hot water temperature too low - Increase hot water temperature to 42 ºC to 65 ºC

Temperature regulation not possible - thermo cartridge calcified - Exchange thermo cartridge

Instantaneous heater didn't work with thermostat - Filters are dirty - Clean the filter / exchange filter

- check valve hasn't moved back - Exchange check valves

Test certificate (see page 40)

Spare parts(see page 40)

Cleaning (see page 36) and enclosed brochure

Operation (see page 36)

Flow diagram (see page 37)

Dimensions (see page 37)

Maintenance (see page 38)

The check valves must be checked regularly according to DIN EN

1717 in accordance with national or regional regulations (at least once

a year). To guarantee the smooth running of the thermostat, it is neces-

sary from time to time to turn the thermostat from total hot to total cold.

Safety Function (see page 35)

The desired maximum temperature for example max. 42º C can be pre-

set thanks to the safety function.

Adjustment (see page 34)

After the installation, the output temperature of the thermostat must be

checked. A correction is necessary if the temperature measured at the

output differs from the temperature set on the thermostat.

Do not use silicone containing acetic acid!

Symbol description



Safety Notes

 Gloves should be worn during installation to prevent crushing and cutting

injuries.

 The arm of the shower head is intended only to hold the shower head. Do not

load it down with other objects!

 Children as well as adults with physical, mental and/or sensoric impairments

must not use this shower system without proper supervision. Persons under the

influence of alcohol or drugs are prohibited from using this shower system.

 Do not allow the streams of the shower touch sensitive body parts (such as your

eyes). An adequate distance must be kept between the shower and you.

 The product may not be used as a holding handle. A separate handle must be

installed.

 The shower system may only be used for bathing, hygienic and body cleansing

purposes.

 The hot and cold supplies must be of equal pressures.

Installation Instructions

• Prior to installation, inspect the product for transport damages. After it has been

installed, no transport or surface damage will be honoured.

• The fitting must be installed, flushed and tested after the valid norms!

• The plumbing codes applicable in the respective countries must be oberserved.

• Where the contractor mounts the product, he should ensure that the entire area of

the wall to which the mounting plate is to be fitted, is flat (no projecting joints or

tiles sticking out), that the structure of the wall is suitable for the installation of the

product and has no weak points. The enclosed screws and dowels are only suit-

able for concrete. For another wall constructions the manufacturer's indications of

the dowel manufacturer have to be taken into account.

• The filter insert must be use to protect the shower against incoming dirt by pipe-

work. Incoming dirt leads to defects or/and can damage parts of the shower;

such caused faults voids all liability and guarantee claims.

• The product is not designed to be used with steam baths!

Technical Data

Operating pressure: max. 1 MPa

Recommended operating pressure: 0,1 - 0,5 MPa

Test pressure: 1,6 MPa

(1 MPa = 10 bar = 147 PSI)

Hot water temperature: max. 80°C

Recommended hot water temp.: 65°C

Centre distance: 150mm

Connections G 1/2: cold right - hot left

Thermal disinfection: max. 70°C / 4 min

Safety against backflow

The product is exclusively designed for drinking water!

English
