Käyttöohje FERM RSM1007 Puukkosaha

Käyttöohje

 Do not use power tools in the rain or wet environments.

 Do not use power tools where there is a risk of fire or

explosion - i.e.near flammable liquids or gases.

 Do not allow children into the area where you are working.

 Do not let children or other people touch electrical power

tools.

 Avoid body contact with grounded (earthed) surfaces

(e.g. pipes, radiators,appliances).

 Do not leave the power tool unattended and always

disconnect from the power supply after use. Store in a dry

place well out of reach of children.

 Always use safety glasses and a dust mask when cutting or

drilling through materials.

 Do not carry a power tool by the cord or pull on the cord

and keep it away from heat, water,oil and sharp objects.

 Wear the right clothes - not loose fitting and ensure

garments cannot come into contact with moving parts.

 If you have long hair,tie it back safely to avoid tangling it in

moving parts.

 Do not use power tools when you are tired or have been

drinking alcohol.

 Wear non-slip shoes, especially if working outdoors.

 When working outdoors and you have no other option than

to use an extension cable,ensure it is suitable for outdoor

use and fitted with the correctly rate fuse.

 Where possible, secure your work piece firmly in a clamp or

a vice to permit the use of two hands.

 Do not overreach while working - you may lose your balance.

 You must switch off your tool at the tool’s on/off switch and

at the power supply.

 Never change a blade, disk or any other attachment without

first turning off the on/off switch on the tool and removing

the plug from the power supply.

 We strongly recommend the use of a residual current device

(RCD) at the power source when using power tools.

 Only use spare parts and attachments supplied by Ferm.Use

of attachments other than those supplied or recommended

by Ferm will invalidate your guarantee and could be

dangerous.

ABOVE ALL - BE CAREFUL!

Mains Plug Replacement

If you in any doubt whatsoever regarding removing the old

plug and reconnecting a new one, you should contact a

competent electrician to do it for you.

 Disconnect the plug from the electric socket.

 Cut off the old plug and dispose of it safely.Under no

circumstances should anyone be able to find and use a plug

with exposed wires.

 Only fit an approved plug with the correctly rated fuse.

 Attach the cores (wires) to their respective terminals.

BROWN - L (Live)

BLUE - N (Neutral)

Ensure the outer cable (sheath) is firmly clamped in place to

avoid strain on the wires at the terminals.

Maintenance

Remove the saw from the power supply.

Carry out a visual inspection before and after you use the saw.

If it appears to be damaged or parts are worn have the saw

repaired by a qualified person.If the blade is worn or damaged

you must purchase a new blade. Using an old worn blade can

be dangerous and hard work!

When the time comes to replace your saw,dispose of it safely

through a recycling facility.

Risk of material damage and/or physical injury.

Risk of an electric shock.

In accordance with the safety regulations of

applicable European guidelines.

Class II machine – Double insulation – An earthed

plug is not necessary.

The number of revolutions of the machine can be

adjusted electronically.

Read the instructions.

Wear safety goggles.

Use a hearing protection aid.

Warning! Always read the instruction for electrical products carefully before use.

It will help you understand your product more easily and avoid unnecessary risks.

Keep this instruction manual in a safe place for future use.

GB

SAFETY INFORMATIONSPARE PARTS LIST FRS-500

322

REF NR DESCRIPTION FERM NR

4 SWITCH 408530

5 SWITCH CAP 408531

14 BRUSH HOLDER 408532

12+13 CARBON BRUSH SET (2 PCS) 408533

11 BRUSH CAP 408534

46+47+49+50 SAWBLADE CLAMP 408535
