SPARE PARTS LIST FCR-18K

REF. NR. DISCRIPTION FERM NR.

1 BATTERY 18 V 818883

2 SWITCH 406654

3 MOTOR 18 V 408752

4 TRANSMISSION 408753

5 SAWBLADE HOLDER 408730/408731

- 1-STD BATTERY CHARGER 406655

SPARE PARTS DRAWING

1

3

2

4

5

18 VOLT CORDLESS ELECTRIC SAW

TECHNICAL DATA

PACKAGE CONTENTS

The package contains:

1 Cordless reciprocating saw

1 Battery, 18 V, 1.3 Ah

1 Battery Charger

1 Saw blade for wood

1 Saw blade for metal

1 User manual

1 Guarantee card

1 Safety instructions

Please examine the saw, individual parts and accessories

for transport damage.

SAFETY INSTRUCTIONS

The following pictograms appear throughout these

operating instructions:

Indicates danger of injury, risk to life and possible

damage to the appliance if these instructions are

not followed.

Indicates the presence of electrical current.

Read through these operating instructions carefully

before using the appliance. Become familiar with the

functions and method of operation. To ensure proper

operation, always maintain the appliance according to

the instructions. The operating instructions and

associated documents should always be kept close to the

appliance.

When using power tools, you must observe the

follwing basic safety precautions in order to ensure

protection from electric shocks, injury and fire.

Read and follow all the instructions before using this

power tool. Look after the notes on safety.

• Remove the battery block. When the power tool is

not being used, prior to maintenance and when

changing tools such as the clamping chuck, and drill.

• The tool is suitable for use as a screwdriver and drill.

Any other application is specifically excluded.

IMPORTANT SAFETY NOTES ON CHARGER

AND BATTERY BLOCK

If you come into contact with acid from the battery

block, rinse it off with water immediately. If acid gets

into your eyes, rinse out your eyes at once with water

and contact a doctor immediately!

1. Read and note the operating instructions and safety

notes for the charger and battery block before use!

2. NB! Only use the charger and battery block that

were supplied by the manufacturer - otherwise you

will risk an accident.

3. Protect the charger, battery block and power tool

from moisture, e.g. rain or snow.

4. Always check that all cables are connected correctly

before using the charger.

5. If you discover that a cable is damaged, you should

not use the charger again. Have the damaged cable

replaced immediately.

6. When the charger is not in use, the mains plug should

be removed from the power socket. Do not pull out

the plug by grasping the cable.

7. If the charger has been dropped or has otherwise

been exposed to high mechanical stresses, you

should have it checked for damage by an authorised

dealer before using it again. Damaged parts should be

repaired.

8. Exercise caution when handling the battery block

and do not drop it or expose it to impacts.

9. Never attempt to repair the charger or battery block

yourself. Repairs must always be carried out by an

authorised dealer - otherwise you risk an accident.

Voltage | 18 V -

Charger voltage | 230 V ~

Charger frequency | 50 Hz

Battery output | 1.3 Ah

Charging time | 1 hour

Revolutions, idling | 0 - 2100/min

Cutting length | 19 mm

Weight (incl. battery) | 1.9 kg

Lpa (sound pressure level) | 84.4 dB(A)

Lwa (operating sound level) | 97.4 dB(A)

Vibration level | 3.1 m/s

2
