10. Before cleaning or servicing the charger or battery
block, always pull the plug from the charger socket.
11. Never charge the battery block when the ambient
temperature is below 10°C or above 40°C.
12. The air vents in the charger must never be blocked.
13. The battery block must not be short-circuited.
A short-circuit will cause a high current to flow. This
may result in overheating, the danger of fire or
explosion of the battery block. This may damage the battery
block or the user may risk an accident.
Therefore:
1. Do not connect any cables to the poles of the battery
block.
2. Take care that there are no metal objects (nails, paper
clips, coins, etc.) on the contact surface of the battery
block.
3. Do not expose the battery block to water or rain.
4, Only use the battery block supplied in combination
with this cordless drill/screwdriver so as to avoid faults
and/or risks to persons.
14. A damaged battery block or one that can no longer
be charged must be disposed of as special waste. Do
not discard it with household waste.
15. Never throw the battery block onto a fire or into
water. This will risk explosion!
ELECTRICAL SAFETY
Always check whether your battery voltage
matches that shown on the rating plate. Also find
out whether your mains voltage matches the input voltage of
the charger.
The battery charger is doubly insulated in
compliance with EN60335; it therefore does not
require earthing.
Replacing cables or plugs
Dispose of old cables or plugs immediately they are
replaced by new ones. Connecting a plug on a loose
cable to a socket is dangerous.
MOUNTING ACCESSORIES
Fig. B
Always remove the battery before starting work.
FITTING AND REMOVING DRILL CUTTERS
In addition to drill cutters, the tool can also
accommodate screwdriver bits with a hexagonal shaft.
• Loosen the drill chuck (4) by rotating the hand-grip
(9).
• Insert the shaft of the drill cutter into the chuck.
• Tighten the drill chuck so that the drill cutter is firmly
clamped.
• Rotate the drill chuck in the opposite direction when
you wish to change the cutter.
CONNECTING AND REMOVING THE
BATTERY
Fig. C
Ensure that the exterior of the battery block or tool
is clean and dry before connecting the charger.
• Ensure that the direction reversing switch (6 Fig. A) is
in the central position in order to prevent the
appliance from being switched on unexpectedly.
• Insert the charger (5) into the base of the appliance,
as shown on the illustration. Push the battery until it
latches in.
• Press the locking buttons (10) on both sides before
removing the battery, and disengage the battery
from the base of the appliance.
OPERATION
Always follow the safety notes and the relevant
safety code.
Hold the appliance firmly and press the drill cutter
steadily onto the workpiece. Do not overload the
appliance.
Only use drill cutters with no visible wear. Worn drill
cutters will have a bad effect on the functioning of the
appliance.
ADJUSTING THE TORQUE
Fig. D
The appliance has 16 different torque settings with
which to set the power for driving and removing screws.
• Set the torque adjustment ring (3) to the desired
position.
The available torque settings are indicated on the
adjustment ring by the numbers 1 to 8 and by dots
between the figures to define intermediate settings
(16 in total).
• You should preferably choose as low a setting as
possible when using the screwdriver. Select a higher
setting if the motor slips.
DRIVING AND REMOVING SCREWS
• Set the direction reversing switch (6) to position 'R'
in order to drive screws.
• Set the direction reversing switch to position 'L' in
order to remove screws.
DRILLING
• Rotate the torque adjustment ring (3) to the drilling
position.
Ensure that the direction reversing switch (6) is
always set to 'R' during drilling.
SWITCHING THE DEVICE ON AND OFF
Fig. A
• Depress the on/off switch (1). It regulates the speed
of the appliance by transmitting power to the switch.
• Release the on/off switch (1) to halt the drill chuck
immediately which will no longer run on.
• Move the direction reversing switch (6) to the centre
in order to lock the appliance in its disabled state.
