Impact drilling.
Select a suitable drill bit for the practice use.
- For drilling in soft material like wood or plastic rotate
the impact sleeve (5) in clockwise until the indicator
points at the mark ‘DRILL BIT’ In this case use a metal
drill bit.
- For drilling in hard material like stone or concrete,
rotate the impact sleeve (5) in anti-clockwise until
the indicator points at the mark ‘HAMMER’. In this
case use a drill bit with carbide tip.
Regular check the chuck for possible damage.
Possible use a coolant. In case of drilling in walls,
watch out for drilling in electric wires of water pipes. Get
advice according to the use from your dealer.
Switching on and off.
Fig. E
• Press the on/off switch (2) in. You regulate the speed
of the machine by the degree to which you keep the
switch pressed in.
• Releasing the on/off switch (2) causes the drill to stop
immediately
• Slide the direction switch (1) to the middle to lock
the machine in switched off mode.
Do not put the machine away until the machine has
completely stopped running. Do not store the machine
on a dusty surface. Dust particles can get into the
mechanism.
Only operate the drill with the forward / reverse
switch (2) fully engaged. Never attend to use the
drill with this switch in the neutral position.
Charging batteries
Fig. F
The enclosed battery charger has been exclusively
designed for loading batteries of the FCD-2400 I.
• Position the battery (7) in the battery charger (9) as
indicated in the illustration.
• Plug in the battery charger. The red “fast charging”
light (10) is then illuminated
• As soon as the green light (11) is illuminated, charging
has finished and the accumulator is ready for use
Only use the battery charger in a dry environment
at a temperature between 10 °C and 40 °C.
The battery on the drilling machine you have purchased
is not charged up. Before using it for the first time leave it
to charge for 1 - 2 hours in order for it to reach its full
capacity. The total capacity of the battery will be reached
after it has been charged 4 – 5 times.
If the cordless drill is not going to be used for a long
period of time, recharge the battery before storing.
From time to time recharge the battery for a short period of
time, to prevent it from running down. Store the battery
separately in the plastic case.
MAINTENANCE
While maintaining and cleaning the machine pull
the plug from the mainssocket. Never use water or
other agressive liquids to clean the machine. Clean the
machine by brushing it with a brush.
The Ferm machines have been designed to operate over
a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon
proper machine care and regular cleaning.
Cleaning
Keep the ventilation slots of the machine clean to
prevent overheating of the motor.
Regularly clean the machine housing with a soft cloth,
preferably after each use. Keep the ventilation slots free
from dust and dirt.
If the dirt does not come off use a soft cloth moistened
with soapy water. Never use solvents such as petrol,
alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
Lubrication
The machine requires no additional lubrication.
Faults
Should a fault occur, e.g. after wear of a part, please
contact your local Ferm dealer.
In the back of this manual you find an exploded view
showing the parts that can be ordered.
ENVIRONMENT
In order to prevent the machine from damage during
transport, it is delivered in a sturdy packaging. Most of
the packaging materials can be recycled. Take these
materials to the appropriate recycling locations.
Take your unwanted machines to your local Ferm-
dealer. Here they will be disposed of in an
environmentally safe way.
NiCd cells are recyclable. Take them to your local Ferm-
dealer or a local recycling station. The collected battery
packs will be recycled or disposed of in an
environmentally safe way.
GUARANTEE
The guarantee conditions can be found on the separately
enclosed guarantee card.
Ferm 5
.
.
