BEFORE USING THE MACHINE:

1. Check the following:

- Make sure that your machine is correct for your

power supply.

- Make sure the socket is earthed;

- Make sure the cable and socket are in good con-

dition, i.e. not frayed or damaged.

2. Do not use long extension cables.

Use only earthed extension cables.

3. A grinding stone is fragile.

The stone is easily damaged when being dropped, hit,

etc. Always grind with the face of the grinding stone,

never the sides. A cracked grinding stone must be

replaced immediately. Due to the high rotational

velocity the stone might disintegrate, causing acci-

dents.

4. Always wear safety glasses when grinding.

5. Never operate the grinding machine without the

guard in place.

6. Make sure the guard and the tool rest are properly

adjusted and secured.

7. The maximum clearance between the tool rest and

the grinding stone must never exceed 1-1.5 mm.

8. Use the stone only for its intended purpose, e.g. for

grinding tools, never for heavy-duty construction

work.

Use only grinding stones that state the following:

- Name of the manufacturer;

- Binding material;

- Dimensions;

- Maximum speed.

9. Never rebore the arbor hole in the grinding stone to

widen the diameter.

10. The maximum admissable rotational velocity of the

grinding stone may not exceed the velocity mentio-

ned on the stone.

11. For safe grinding it is best to bolt the machine to the

bench.

BEFORE YOU OPERATE THE MACHINE:

1. Make sure the switch is “OFF” before you plug in the

machine.

2. Keep the cable away from moving parts.

SWITCH OFF THE MACHINE IMMEDIATELY

IN CASE OF

1. Malfunction in the mains plug, power cable or dama-

ging of cable.

2. Broken switch.

3. Smoke or stench of scorched insulation.

INSTALLATION

Fig. B.

The holder of a cover glass, together with the cover

glasses themselves will always be adjusted/moun-

ted with the grinding stone being out of action and the current

turned out.

The grinding machine has to be secured to the bench by

means of bolts. The length of the bolts depends on the

thickness of the bench. If your bench is made of steel, it is

best to place the machine on a supporting, wooden plate

to separate it from the bench, to avoid vibrations.

MOUNTING AND ADJUSTMENT THE

COVER GLASSES AND HOLDERS

- Mount the holder of the cover glass together with

the cover glass itself, by means of the screw (A).

- Adjust the height of the holder of the cover glass by

loosening a bit screw . The free space between the

stone and the holder of the cover glass will amount

to 1 - 1,5 mm.

- Fasten well screw (A).

- Adjust the cover glass (see the figure above) in such a

way that your face will be protected, at the utmost.

- Use always safety glasses.

ADJUSTING THE TOOL REST.

Disconnect the machine and make sure the grin-

ding stone has stopped before adjusting the tool

rest.

Secure the tool rest, allowing a maximum clearance (C)

between the tool rest and the grinding stone of 1 - 1.5

mm.

REPLACING THE GRINDING STONE

Fig. C.

Disconnect the machine and make sure the grinding

stone has stopped before replacing the grinding

stone. Disconnect the machine and make sure the grinding

stone has stopped before replacing the grinding stone.

Required tools:

- spanner, 19 mm;

- spanner, 8 mm;

- screwdriver.

- Remove the guards, using the above tools. When

replacing the stones, remember the right-hand

spindle is fitted with right-hand thread, the left-hand

spindle with left-hand thread.

- Loosen the nut by means of the spanner. Remove the

stone.

- Clean the flanges. Replace one flange, with the con-

cave side facing the grinding stone. Slide the new grin-

ding stone on to the spindle. Replace the second

flange on the spindle,

with the concave side facing the grinding stone. Tigh-

ten the nut securely, but not too tightly! Replace the

guards and adjust the tool rest. Let the motor run for

a few seconds before you start to grind.
