English

Ver. 20210215

Dynamo Radio

Art.no 39-1227 Model MD-088P

Please read the entire instruction manual before using the product and then save it for future

reference. We reserve the right for any errors in text or images and any necessary changes

made to technical data. In the event of technical problems or other queries, please contact

our Customer Services (see address details on the back).

Safety

• The product must not be taken apart or

modified.

• The product must only be repaired by a

qualified service technician.

• Do not expose the product to extremely high

temperatures such as a hot summer's day in

the car.

• Do not point the beam of the torch at

anyone’s eyes.

• Do not use the product in an area where

flammable liquids or gases are used or

stored.

• Protect your hearing. Do not listen with a

high volume for prolonged periods as it can

lead to permanent hearing loss.

• The product should never be used if the

battery compartment cover is in any way

damaged or malfunctioning.

• Never let children play with the product.

Responsible disposal

This symbol indicates that the product should not be disposed of with

general household waste. This applies throughout the entire EU. In order

to prevent any harm to the environment or health hazards caused by incor-

rect waste disposal, the product must be handed in for recycling so that

the material can be disposed of in a responsible manner. When recycling

your product, take it to your local collection facility or contact the place of

purchase. They will ensure that the product is disposed of in an environme-

ntally sound manner.

Buttons and functions

1. Bulb

2. Charging indicator

3. Battery capacity

4. [ ] ON/OFF, torch push-button switch

5. AM/FM aerial

6. Crank

7. Solar panel

8. Radio signal indicator

9. Speaker

10. [SOS] Alarm button

11. [OFF/-VOL+] Radio on/off and volume knob

12. [AM/FM] selector

13. [<TUNING>] Radio channel tuning knob

14. USB input

15. USB output

Charging the dynamo radio

Blue LEDs indicate the capacity of the battery for 30 seconds immediately after the radio or

torch is switched on. The indicators then go out to save battery power.

25% 50% 75% 100%

Using the solar panel

• The solar panel has a lifespan of over 25 years if it is used about 6 hours per day.

• The solar panel can be used for maintenance charging of the battery, but the torch and

radio should be switched off for best results.

Position the radio where the solar panel is exposed to as much sunlight as possible

The charging indicator will light.

Using the crank

1. Extend the crank handle from the rear of the radio.

2. Wind the crank in either direction for a few minutes. The charging indicator will

light while the crank is wound.

Power:

60 winds/min in one hour will charge the battery with approximately: 200mAh

120 winds/min in one hour will charge the battery with approximately:350mAh

Max charging current 600mA

From a fully-discharged battery state, winding the crank for approximately 3 minutes will

provide 10 minutes of radio listening.

Using a wall socket

Connect a Micro-USB cable to the USB input on the dynamo radio and to a USB charger of

your choice. The blue LED indicators will light to show the charge status of the battery. When

all four indicators shine steadily the battery is fully charged (approximately four hours).

Charging external devices

• The included cable is only intended for charging devices having a Micro-USB port.

• The dynamo radio is capable of charging telephones in an emergency, but should not be

used regularly as a power bank.

Connect the included charging cable (or the charging cable of the device to be charged) to

the USB output port on the radio and to the external device.

Playing the radio

When the battery is fully charged the radio can play for approximately 15–18 hours.

1. Extend the aerial completely. It might need to be adjusted a little to pick up a clear signal.

2. Slide the [AM/FM] switch to the desired frequency band.

3. Turn the [OFF/-VOL+] knob to switch the radio on and set the volume.

4. Turn the [<TUNING>] knob to select the desired channel. The radio signal indicator will

light when a strong radio channel signal has been tuned into.

5. Turn the [OFF/-VOL+] knob to [OFF] to switch the radio off.

The SOS alarm button

NOTE: The siren sound is very loud. The SOS feature should only be used in an emergency.

1. Press the [SOS] button twice. The light inside the button will flash in time with a loud siren

signal.

2. Press the [SOS] button again to turn the alarm off.

Torch function

When the battery is fully charged the torch can be used for approximately 10–12 hours.

1. Press the [ ] button to switch the torch on.

2. Press the [ ] button again to switch the torch off.

Care and maintenance

• Clean the dynamo radio by wiping it with a moist cloth. Use only mild cleaning agents,

never solvents or corrosive chemicals.

• Fully charge the dynamo radio every third month if it is not to be used for a long time.

• Store the dynamo radio in a dry, dust-free place out of children’s reach.

Troubleshooting guide

The radio is not charged by the solar panel. Clean the solar panel using a soft cloth.

Place the radio outdoors in bright sunlight.

The radio is not charged by the USB cable. Check all cables, connections and the USB

charger. Check that there is power at the

wall socket.

Specifications

Charging 5 V DC, 1000 mA

Output USB 5 V, 1000 mA

Batteries 3.7 V, 2000 mAh, 18650 Li-ion

IP rating IPX3

LED torch 1 W / 80 lm

Dimensions 145x60x75mm

Weight 300 g

15

14

<

T

U

N

I

N

G

>

12

13

6

7

9

11

10

8

1

5

4

2

3
