Käyttöohje

GREAT BRITAIN - CUSTOMER SERVICE contact number: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk

English

Ver. 20130829

Cross-cut Shredder

Art.no 18-8053 Model CO50-UK

38-1487 CO50

Please read theentire instruction manual before using theproduct

and save it for future reference. Wereserve theright for any errors

in thetext or images and any necessary changes made to technical

data. Ifyou have any questions regarding technical problems please

contact our Customer Services.

Safety

• Place themachine as close to awall outlet as possible.

• Always remove theplug from thewall socket before moving or

cleaning theshredder.

• Always remove theplug from thewall socket before emptying

the waste collector bin. Empty thecollector bin regularly in order to

avoid jamming themachine because of thecontainer being over full.

• Never open thecasing. If you should have problems with

the shredder, contact Customer Services.

• The product is designed exclusively for domestic use.

The machine is not designed for commercial use.

Warning symbols

Getting started

1. Place theshredder unit onto thewaste container. Thereis asafety

lock on theunderside edges of theshredder. Theseare depressed

when theshredder is placed correctly on thewaste container.

Thesemust be depressed in order for theshredder towork.

2. Place thewaste container on aneven and stable surface.

3. Connect theplug to awall outlet with 220–240 V AC voltage rating.

Operation

The control switch has 3 settings:

• AUTO

Automatic start. Whentheswitch is in this mode theshredder

will start automatically when thepaper is placed in thefeeder

opening. Whenthepaper is fed through themachine will turn

off automatically. Ifit does not turn off, make sure that thewaste

container is not full or that there are no paper remnants stuck in

theshredder.

• REV

Reverse function. Usedto remedy apaper jam. Ifyou notice that

theshredder is overloaded and starts to struggle or stop, you

must immediately set thecontrol switch in REV mode. Thisallows

theblades to rotate backwards and thepaper can be fed back

out ofthefeederopening.

• OFF

The machine is in theOFF position.

Capacity

• The shredder can process up to 5 sheets (A4, 80 g) at one time.

Ifyou run thicker paper stock thenumber of sheets theshredder

can process is reduced. Themaximum width of thepaper should

be 22cm (A4).

• If you want to shred smaller sheets of paper, you should feed them

in thecentre of thefeeder opening. Otherwise, theshredder will

not start automatically.

Avoiding overloading and jamming

The shredder is equipped with overload protection. Whenactivated

theshredder shuts off when, for example, trying to feed more

than 5 sheets in at atime.

To reset theshredder after theoverload protection has tripped:

1. Remove theplug from thewall socket and let theshredder cool

for 30 min. Cleartheblades of any paper remnants.

2. Connect theplug to awall socket and set thecontrol switch to

REV mode. Excesspaper remnants will exit through thefeeder

opening. Removetheplug from thewall outlet and remove any

paper remnants from theblades.

3. Set theswitch to AUTOmode.

Care and Maintenance

• Always unplug themachine from thewall socket before cleaning.

• The blades need no maintenance and do not need lubrication.

• Clear theblades from paper remnants using asharp object.

• Dry theexterior and container using adrycloth.

• Never use flammable cleaning agents.

• Empty thewaste container regularly. Afull waste container can

contribute to adiminished functioning of theshredder.

Disposal

Follow local ordinances when disposing of this product.

Ifyou are unsure of how to dispose of this product,

please contact your municipality.

Specifications

Type Cross-cut

Cross-cut size Approx. 4×40mm

Capacity 5 sheets (80 g) simultaneously

Feeder width 220mm

Shredder size Approx. 300×185×305mm

Power supply 220–240 V AC, 50 Hz, 0.8A

Power 184W

General warning symbol.

Read theinstructions before use.

Keep your hands away from thefeeder opening.

Keep your hair away from thefeeder opening.

It may be pulled in and injure you.

Keep loose hanging objects, like clothes, ties, etc away from

thefeeder opening. They may be pulled in and damaged.

Keep loose hanging jewellery away from thefeeder opening.

They may be pulled in and damaged.

Remove all paper clips and staples before running them

through theshredder.

The shredder is designed only for shredding paper. It is not

suited for any other materials. The paper must be clean and

dry. Do not insert CDs/DVDs into thefeeder opening.

This product is not atoy and must not be used by children.

Never leave theshredder unattended when in operation.

DO NOT use sprays when cleaning theshredder’s interior

or exterior. DO NOT use flammable substances in thenear

vicinity of theproduct. DO NOT use sprays directly in or in

thevicinity of thefeeder opening.
