Käyttöohje Cylinda IHI 9161S Keittotaso

Käyttöohje

DAILY USE

SWITCHING THE HOB ON/OFF

To turn the hob on, press the power button for around 1 second.

To turn the hob o, press the same button again, and all cooking zones

will be deactivated.

POSITIONING

Locate the desired cooking zone by referring to the position symbols.

Do not cover the control panel symbols with the cooking pot.

Please note: In the cooking zones close to the control panel, it is advisable to

keep pots and pans inside the markings (taking both the bottom of the pan

and the upper edge into consideration, as this tends to be larger).

This prevents excessive overheating of the keypad. When grilling or frying,

please use the rear cooking zones wherever possible.

ACTIVATING/DEACTIVATING COOKING ZONES AND

ADJUSTING POWER LEVELS

To activate the cooking zones:

Select the pre-selected cooking zone by pressing the

corresponding zone

selection

button. The display will show level ”0”.

Use the scroll device to select the required power level (from min. 0 to max. 9).

To increase the power level, swipe your nger over the slider from left to right

(or from right to left if you want to reduce the level). Alternatively, use the ”+”

and ”−” buttons.

Some cooking areas have a quick heating function (Booster). To activate

this function, swipe your nger over the scroll device several times from

left to right until the display shows ”P”.

Power indicator display

Selected cooking zone indicator

To deactivate the cooking zones:

Select the cooking zone to be switched o by pressing the corresponding

zone selection

button (a dot will light up on the display, to the bottom

right of the power level indicator). Press the ”−” to set the level to ”0”.

Alternatively, swipe your nger over the slider several times from right to

left until the display shows ”0”.

To switch o immediately, press and hold the zone selection button for

3



seconds. The cooking zone is deactivated and the residual heat indicator

”H” appears on the display.

CONTROL PANEL LOCK

To lock the settings and prevent it being switched on accidentally, press

and hold the Timer activation/Key lock button for 3 seconds. A beep

and a warning light above the symbol indicate that this function has

been activated. The control panel is locked except for the switching o

function (

). To unlock the controls, repeat the activation procedure.

TIMER

The timer enables a cooking time to be set for all of the zones.

To activate the timer:

Select and activate the cooking zone for which you wish to set the timer.

Press the button with the clock icon and set the desired time, using the ”+”

and ”−” buttons. The timer LED for the zone in use will be illuminated.

A few seconds after the last touch, the timer will start the countdown and

the dot on the display that indicates that the seconds are passing will ash.

When the set time is up, an acoustic signal will sound and the cooking

zone will switch o automatically.

After selecting the zone and the clock icon, the time can be changed at

any point, and several timers can be activated simultaneously.

The timer always shows the time set for the selected area, or the shortest

remaining time.

When more than one timer is active, the ashing LED indicates the zone

for which the cooking time is visible on the display.

To set the timer for another zone, repeat the above steps.

To deactivate the timer:

Select the cooking zone for which you wish to deactivate the timer.

Press the button with the clock icon

( ).

Press and hold the

”−” button

, or swipe your nger over the slider several

times from right to left until the display shows ”0:0”.

INDICATORS

RESIDUAL HEAT

If ”H” appears on the display, this means that the cooking zone is hot.

The indicator lights up even if the zone has not been activated but has

been heated due to the use of the adjacent zones, or because a hot pot

has been placed on it.

When the cooking zone has cooled down, the ”H” disappears.

POT INCORRECTLY POSITIONED OR MISSING

This symbol appears if the pot is not suitable for induction cooking, is not

positioned correctly or is not of an appropriate size for the cooking zone

selected. If no pot is detected within 30seconds of making the selection,

the cooking zone switches o.
