Cleaning the Burner Assembly

Carryover tube

Electrode

Burner

bracket

Pry off

electrode with

a flat blade

screwdriver

Storing Your Appliance

General Appliance Cleaning

Høyre

skinne

•Clean appliance often, preferably after each cookout. If a

bristle brush is used to clean any of the appliance cooking

surfaces, ensure no loose bristles remain on cooking surfaces

prior to grilling. It is not recommended to clean cooking

surface while appliance is hot. Appliance should be cleaned

at least once a year.

•Do not mistake brown or black accumulation of grease and

smoke for paint. Interiors of gas grills are not painted at the

factory (and should never be painted). Apply a strong

solution of detergent and water or use a appliance cleaner

with scrub brush on insides of appliance lid and bottom.

Rinse and allow to completely air dry. Do not apply caustic

appliance/oven cleaner to painted surfaces.

• Plastic parts: Wash with warm soapy water and wipe dry.

• Do not use citrisol, abrasive cleaners, degreasers or a

concentrated appliance cleaner on plastic parts. Damage to

and failure of parts can result.

•Porcelain surfaces: Because of glass-like composition, most

residue can be wiped away with baking soda/water solution or

specially formulated cleaner. Use nonabrasive scouring

powder for stubborn stains.

•Painted surfaces: Wash with mild detergent or nonabrasive

cleaner and warm soapy water. Wipe dry with a soft

nonabrasive cloth.

•Stainless steel surfaces: To maintain your appliance’s high

quality appearance, wash with mild detergent and warm

soapy water and wipe dry with a soft cloth after each use.

Baked-on grease deposits may require the use of an abrasive

plastic cleaning pad. Use only in direction of brushed finish to

avoid damage. Do not use abrasive pad on areas with

graphics.

• Cooking surfaces: If a bristle brush is used to clean any of the

appliance cooking surfaces, ensure no loose bristles remain

on cooking surfaces prior to grilling. It is not recommended to

clean cooking surfaces while appliance is hot.

•Clean cooking grates.

•Store in dry location.

•When gas cylinder is connected to appliance, store outdoors

in a well-ventilated space and out of reach of children.

•Cover appliance if stored outdoors.

•Store appliance indoors ONLY if gas cylinder is turned off and

disconnected, removed from appliance and stored outdoors.

•When removing appliance from storage check for burner

obstructions.

9. Attach electrode to burner.

10. Carefully replace burners.

11. Attach burners to brackets on firebox.

12. Reposition carryover tubes and attach to burners.

Replace flame tamers and cooking grates.

VERY IMPORTANT: Burner tubes must

reengage valve openings. See illustration.

Follow these instructions to clean and/or replace parts of burner

assembly or if you have trouble igniting appliance.

1. Turn gas off at control knobs and cylinder.

2. Remove cooking grates, flame tamers, carryover tubes and

burners.

3. Detach electrode from burner.

4. Carefully lift each burner up and away from valve openings.

5. We suggest three ways to clean the burner tubes. Use the

one easiest for you.

(A) Bend a stiff wire (a light weight coat hanger works well)

into a small hook. Run the hook through each burner

tube several times.

(B) Use a narrow bottle brush with a flexible handle (do not

use a brass wire brush), run the brush through each

burner several times.

(C) Wear eye protection: Use an air hose to force air into

burner tube and out burner ports. Check each port to

make sure air comes out each hole.

6. Wire brush entire outer surface of burner to remove food

residue and dirt.

7. Clean any blocked ports with a stiff wire such as an open

paper clip.

8. Check burner for damage, due to normal wear and corrosion

some holes may become enlarged. If any large cracks or

holes are found, replace burner.

Correct burner-to-

valve engagement
