54
PARTS
1. Brew Head
2. Porta-Filter for Ground Coffee and E.S.E. pods
(45mm)
3. Height Adjusting Slot for Small Cups
4. Removable Drip Grid
5. Removable Drip Tray
6. DripTrayOverowFloater
7. Filters For:
a. Single Shot of Espresso and E.S.E. pods
(45mm)
b. Double Shot of Espresso
c. Detachable Bottom Covers of Filters
8. Measuring Scoop/Tamper
9. Control Panel
a. Single and Double Espresso Button with
Indicator Lights
b. Manual Espresso Brew Button with Indicator
Light
c. Small and Large Cappuccino Button with
Indicator Lights
d. Small and Large Latte Button with Indicator
Lights
e. Manual Milk Frothing Button with Indicator
Light
f. Clean Button with Indicator Light
10. Removable/Clear Milk Reservoir
11. Milk Reservoir Lid
12. Milk Reservoir Release Button
13. Milk Froth Level Control Knob
14. Milk Frothing Tube Guide Lever
15. Frothed Milk Dispensing Tube
16. On/Off Switch “I/O”
17. Removable Water Tank
18. Water Tank Lid
19. Milk Hose
INTRODUCTION
Congratulations! You have selected the new and
innovative Breville
®
One-Touch CoffeeHouse. This
unique appliance has been designed to help you prepare
delicious espressos, cappuccinos and lattes quickly,
conveniently, and automatically with the touch of a button.
ESPRESSO
A unique method of coffee brewing in which hot water is
forcedthroughnelygroundcoffee.PopularinEurope,
it is a far richer and more full-bodied brew than regular
drip coffee. Because of its richness, espresso is usually
served in 45 to 60 ml (1.5 to 2 oz.) portions, in demitasse
cups.
CAPPUCCINO
A drink made with about 1/3 espresso, 1/3 steamed milk,
and 1/3 frothed milk.
LATTE
A drink made with about 1/4 espresso and 3/4 steamed
milk.
Please read ALL of the instructions, cautions, notes and
warnings included in this instruction manual carefully
before you begin to use this appliance. When this unit is
used, some parts and accessories get hot and need to
cool down. Proper care and maintenance will ensure the
long life of the Breville
®
One-Touch CoffeeHouse and its
trouble-free operation. Save these instructions and refer
to them often for cleaning and care tips.
Your Breville
®
One-Touch CoffeeHouse can be used with
ground coffee as well as E.S.E. pods (45 mm), making
it exceptionally practical and versatile to prepare single
shots of espresso, cappuccino and latte.
IMPORTANT SAFETY INFORMATION
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children unless they are older than 8
and supervised. Keep the appliance
and its cord out of the reach of children
aged less than 8 years.
If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualied
persons in order to avoid a hazard.
• This appliance generates heat during use. Adequate
precaution must be taken to prevent the risk of burns,
scalds,resorotherdamagetopersonsorproperty
caused by touching the exterior whilst in use or during
cooling.
• Never use this appliance for anything other than its
intended use. This appliance is for household use only.
Do not use this appliance outdoors.
• Always ensure that hands are dry before handling the
plug or switching on the appliance.
• Always use the appliance on a stable, secure, dry and
level surface.
• This appliance must not be placed on or near any
potentially hot surfaces (such as a gas or electric hob).
• Do not use the appliance if it has been dropped, if
there are any visible signs of damage or if it is leaking.
• Ensure the appliance is switched off and unplugged
from the supply socket after use and before cleaning.
• Always allow the appliance to cool before cleaning or
storing.
• Never immerse any part of the appliance or power cord
and plug in water or any other liquid.
• Never let the power cord hang over the edge of a work
top, touch hot surfaces or become knotted, trapped or
pinched.
• Never leave the appliance unattended when in use.
FITTING A PLUG - U.K. AND IRELAND ONLY
This appliance must be earthed.
IIf the plug is not suitable for the socket outlets in your home, it
can be removed and replaced by a plug of the correct type.
If the fuse in a moulded plug needs to be changed, the fuse
covermustberetted.Theappliancemustnotbeusedwithout
thefusecovertted.
If the plug is unsuitable, it should be dismantled and removed
fromthesupplycordandanappropriateplugttedasdetailed.
If you remove the plug it must not be connected to a 13 amp
socket and the plug must be disposed of immediately.
If the terminals in the plug are not marked or if you are unsure
abouttheinstallationoftheplugpleasecontactaqualied
electrician.
Blue
(Neutral)
Brown
(Live)
Fuse
Green/Yellow
(Earth)
Plug should be ASTA approved to BS1363
Fuse should be ASTA approved to BS1362
Ensure that the outer sheath of
the cable is firmly held by the cord grip
13A
GB GB
