ENGLISH

(Original instructions)

J3 Beater bar Touch Button

Allows you to turn the beater bar function on and off.

J4 Power indicator

Allows you to monitor the level of power being used.

J5 BATTERYSENSOR Indicator

The LED battery indicator displays the remaining charge and warns you

when the battery is low. The nal LED will ash continuously when there

is only 1 minute of runtime remaining. All LEDs will ash when the unit is

discharged.

J6 FILTERSENSOR

Smart sensor technology automatically detects (the symbol will light red)

when the lter becomes clogged and needs to be cleaned.

Note: The FILTERSENSOR LED will flash and the unit will

automatically shut down when there is any obstruction in the

flexible hose or filters which is causing the motor to overheat.

Disconnect and remove the blockage immediately.

Using the handle / wand (Fig. B, C, D, E)

u Press the handle / wand release button (11) to free the

handle / wand (3) from the chassis (12).

u Free the hose connector (9) from the chassis hose port

(13) as shown in gure B.

u Press the chassis release button (12b) to release the hand

held vac (5) from the chassis (12) as shown in

gure C.

u Connect the hose connector (9) to the exible tube port

(3a) ensuring that the latch (9a) clicks securely into place

as shown in gure D.

u Extend the crevice tool (4) as shown in gure E, until it

clicks in place.

u To retract the crevice tool (4) press the tube extension

latch (3b) allowing it to return to its normal position.

Using the 3-in-1 accessory tool (Fig. F)

u The 3-in-1 handle / wand (15) has three congurations.

1. Brush mode.

2. Small crevice mode.

3. Upholstery mode.

u The 3-in-1 handle / wand can be tted either directly to the

hose connector 9 or to the extendable crevice tool (4) as

shown in gure F.

Removing and clearing the beater bars

(Fig. G, H)

u To remove the beater bar cassette (14a) from the oor

head (14) Depress the release button (14b) as shown in

gure G.

u The beater bar (18) can now be removed.

The end pieces are also removable allowing you to clear

the brushes from any hair or other debris that may have

accumulated as shown in gure H.

Note: If an object gets caught in the beater bar it automatically

stops. Turn the unit off, remove object and continue.

Note: The CUA625BHP unit is supplied with a specialised pet

beater bar (18a) for cleaning pet hairs etc.

Charging (Fig. I)

u Place the appliance into the charging base (7) as shown in

gure I .

u Plug the charging base (7) into an electrical outlet.

u Switch the electrical outlet on. The LED charging indicator

will ash and increase in sections.

LEDs go out when fully charged.

u The appliance must be charged for 6 hours.

Note: The Charging base is supplied with 2 screws and wall

plugs for securing it to a wall, providing extra stability, as

shown in gure I.

Battery Sensor LED Patterns

Battery Fault (All LEDs)

Charger Fault (All LEDs)

Battery Hot (All LEDs)

Battery diagnostics

If the appliance detects a weak battery, the charging indicator

will ash at a fast rate when the power button is activated.

Proceed as follows:

u Plug in the charger. Switch on at the mains.

u Leave the appliance to charge.

If the appliance detects a damaged battery, the charging

indicator will ash at a fast rate when the appliance is on

charge. Proceed as follows:

u Take the appliance and the charger to be tested at an

authorised services centre.

Note: It may take as long as 60 minutes to determine that

the battery is defective. If the battery is too hot or too

cold, the LED will alternately blink, fast and slow, one

ash at each speed and repeat.

Emptying the dust bowl (Fig. K, L, N)

u Holding the unit over a suitable waste receptacle, press

the dust bowl release button (6a) to release the dust bowl

lid (6) as shown in gure K.

u Push the compacting handle (19) down to empty the

contents of the dust bowl (5a) as shown in gure L.
