Käyttöohje

BOH1503/2003/2503

Fig. 1

Fig. 2

A

B

C

E

F

G

L

H

I

J

1

3

2

1

3

2

Fig. 3

D

L

G

K

M

N

O

O

4 5

PLEASE READ AND SAVE THESE

IMPORTANT INSTRUCTIONS

When using electrical appliances, basic safety

precautions should always be taken including

the following:

1. Before connecting the heater, check that the

voltage indicated on the rating plate

corresponds to the main voltage in your

home/office.

2. WARNING: In order to avoid overheating,

do not cover the heater ( ) Reference to

product.

3. DO NOT position the heater directly under

a power socket.

4. DO NOT use this heater in the immediate

surroundings of a bath, a shower or a

swimming pool.

5. If the supply cord orplug is damaged, it must

be replaced bythe manufactureror its service

agent or similarly qualified person in order to

avoid hazard. The heater contains no user

serviceable parts. Should the product suffer

damage or breakdown, it must be returned to

the manufacturer or their serviceagent.

6. Under the environment with electrical fast

transient, the product may malfunction.

7. DO NOT use this heater with a

programmer, timer or any other device

that switches the heater on automatically,

since a fire risk exists if the heater is

covered or positioned incorrectly.

8. Only touch the heater with dry hands.

9. DO NOT use this heater outdoors.

10.DO NOT position where it can be touched by

children, especially the very young.

11. Allow a safe area around the heater away

from furniture or other objects; at least 50 cm

from the top and sides and 200 cm at the

front. The heater is to be placed at least 3m

from water source.

12.DO NOT use this heater when it is lying on

its side.

13.DO NOT use the heater in rooms with

explosive gas (e.g. petrol) or while using,

oxygen, inflammable glue or solvent (e.g.

when gluing or varnishing parquet floors,

PVC etc.)

14.DO NOT insert any objects into the heater.

15.Keep the mains cord at a safe distance from

the main body of the heater.

16.If overheating should occur, the built-in

overheating safety device will switch off

the heater.

17.DO NOT place the cord under a rug.

18.The heater cannot be used adjacent to

curtains or combustible material. Curtains or

combustible material may be burned if the

heater was installed incorrectly.

19.This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that

they do not play with the appliance.

20.This heater is filled with a precise quantity of

special oil. Repairs requiring opening of the

oil container are only to be made by the

manufacturer or his service agent who

should be contacted if there is an oil leak;

21 When scrapping the heater, follow the

regulations concerning the disposal of oil.

DESCRIPTIONS (See Fig. 1, 2 & 3)

A. Heated Fins

B. Vents

C. Pull down handle

D. Front Panel

E. Cord Storage.

F. Power cord

G. Front castor assembly

H. Thermostat Knob

I. Power light

J. Control Knob

K. Front wing nut

L. Castor

M. Rear Castor assembly

N. Rear wing nut

0. U bolt

Technical Specifications

BOH1503

Wattage: 1500W

BOH2003/B

Wattage: 2000W

BOH2503

Wattage: 2500W

ASSEMBLY INSTRUCTIONS (See Fig. 3)

Please make sure the heater has not been

plugged into any electricity outlet.

Carefully remove heater from box. Some

accessories are packed internally. Please make

sure you have all of the following accessories

prior to throwing away packaging.

2 Castor assemblieswithfourcastors(M,G& L),

and

2 U Bolts with wing nuts (O, K, N).

ENGLISH

Note:This unit is for FLOOR USE ONLY.

1. Turn the heater upside down and you will see

2 U bolt's (O) with wing nuts over the first and

last joint of the heater.

2. Unscrew the wing nuts (N & K) from the U-

bolts (O).

3. Start with the front of the unit and place one

hole of the front castor assembly (G) to the L

shape of the U-bolt (O) and the other hole of

the castor assembly into the other end of the

U-bolt, then screw on the wing nut (K).

4. Repeat step 3 for the rear castor assembly,

using wing nut (N) instead of wing nut (K) and

rear castor assemblies (M).

5. Use your hand to press the four castors (L)

onto the four axes of the two foot plates until

you hear them click into place. Use your hand

to turn the castors and if they move smoothly

they have been installed properly.

6.After installation of the front and rear castor

assemblies and the castorsturnthe heater the

right way up: the heater is nowready for use.

NOTE: Make sure when assembling that the

castor assemblies with wheels are pointing

outwards for maximum stability.

OPERATING INSTRUCTIONS

(See Fig. 1&2)

1. Set the unit to the OFF (O) position.

2. Plug in heater.

3. SettheThermostatKnob(H)allthewayto

theright.

4.Turnthe ControlKnob(J)todesiredlevelofheat.

BOH1503: 1 = 700W, 2= 800W, 3= 1500W

BOH2003/B: 1= 900W, 2= 1100W, 3= 2000W

BOH2503: 1= 1200W, 2= 1300W, 3= 2500W

NOTE:When the heater is in use, it is

normal that the heater cycles ON and OFF,

this is to maintain your desired temperature.

After using the heater, turn the Control Knob (J)

to “0” position, turn the Thermostat Knob (H) to

lowest temperature position and unplug the

heater from the socket.

SETTING THE THERMOSTAT

1. Set the Thermostat control all the way to max.

2. When the desired temperature/comfort level is

reached, turn the thermostat control

anti-clockwise to a lower position or until the

heater stops operating.

3. The control will now automatically maintain

the pre-set temperature level by turning the

heater ON and OFF.

NOTE:The Power light will remain lit during

operation.

NOTE:It is normal for the heater to cycle ON

and OFF as it maintains the preset temperature.

FROST GUARD INSTRUCTION

Plug the heater in, then select the highest heat

setting (3), then turn thermostat knob to the lowest

temperature position( ), thetemperature willbe

maintained at 5° C, thus the heater will be in the

off status unless the room temperature is lower

than 5°C. If the room temperature islower than

5° C, the heater will automatically start working

and will keep turning on & offall the time,

maintaining itsambient temperature of 5° C.

NOTE:Unit must be unplugged for it to be

fully off.

TIP OVER PROTECTION

When the unit is accidentally knocked over, or

tilts on one side at more than a 45° angle; it

will instantly shut off. To reset, simply place the

heater in an upright position.

TRANSPORTING THE UNIT

Locate the pull down handle (C) above the control

panel. Pull down to release and then grasp the

handle. Pull the unit using the handle ensuring

that all castors are in contact with the floor.

NOTE:Do not use handle to lift the product.

STORAGE TIPS

If the heater is not required for long periods, for

example during the summer, it should be stored

at room temperature; in a dry place and

preferably covered to prevent the accumulation

of dust and dirt.

GUARANTEE

Please keep your receipt as this will be required

for any claims under this guarantee.

This appliance is guaranteed for 5 years after

your purchase as described in this document.

During this guaranteed period, if in the unlikely

event the appliance no longer functions due to a

design or manufacturing fault, please take it

back to the place of purchase, with your till

receipt and a copy of this guarantee.

The rights and benefits under this guarantee are

additional to your statutory rights, which are not

affected by this guarantee. Only Holmes

Products (Europe) Ltd. (“Holmes”) has the right

to change these terms.

Holmes undertakes within the guarantee period

to repair or replace the appliance, or any part of

appliance found to be not working properly free

of charge provided that:

• you promptly notify the place of purchase

or Holmes of the problem; and

• the appliance has not been altered in any

way or subjected to damage, misuse,

abuse, repair or alteration by a person

other than a person authorised by Holmes.

BOH1502-2003-2503-I_IB_REV.qxd:BPH1515I06MLM1.qxd 5/12/10 10:22 AM Page 3
